Auto Industry 3kg Pneumatic Soft Gripper Used In Robots

Certification
China Beijing Soft Robot Tech Co.,Ltd certification
China Beijing Soft Robot Tech Co.,Ltd certification
I'm Online Chat Now

Auto Industry 3kg Pneumatic Soft Gripper Used In Robots

Auto Industry 3kg Pneumatic Soft Gripper Used In Robots
Auto Industry 3kg Pneumatic Soft Gripper Used In Robots

Large Image :  Auto Industry 3kg Pneumatic Soft Gripper Used In Robots

Product Details:
Place of Origin: Beijing,China
Brand Name: Soft Robot Gripper
Certification: FDA CE ISO
Model Number: SFG-FCA4-M5086
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton Package
Delivery Time: 2-3 work days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: Depending on the order quantity

Auto Industry 3kg Pneumatic Soft Gripper Used In Robots

Description
Name: Soft Robot Gripper Model: SFG-FCA4-M5086
Certification: FDA CE ISO Load: 3000g
Application: Automobile Industry, Foodindustry, 3C, Medical Equipment, Etc Material: Food-grade Silica Gel
Smax: 55mm Weight: 944g
High Light:

3kg Pneumatic Soft Gripper

,

55mm Pneumatic Soft Gripper

,

ISO soft gripper used in robots



Pneumatic Soft Gripper - SFG-FCA4-M5086



Product Description

Time saving is cost saving, SRT Soft Flexible Gripper provides you with more efficient production solutions.


Parameter
Model Dimensions(mm) Gripping Capacity
φb Wn Dn Lb Lt Ln L Smax Ymax

Dn+2Smax

(mm)

SFG-FCA3-M5086 208.5 50 70-141 69 63.5 107 86 55 63.3 70-251


Advantage

Soft, Safe, Durable, Food Safety

Has passed FDA, CE, ISO9001 certification

One gripper for complex gripping problem
Heavy cargo handling small expert
Not damage the product packaging and the contents inside
Pick and place operations in many industrial production

Automate with SRT soft robot gripper



Product Detail

Standard working lifespan: ≥3,000,000 times

Load:3000g

Maximum working pressure: 100 kPa

Air tube diameter: 6 mm

Weight: 944g

Auto Industry 3kg Pneumatic Soft Gripper Used In Robots 0


Applications

SRT flexible gripper has various models, aiming at different shapes, sizes and weights, it has launched targeted solutions:

1. Ball-like and flat objects should choose circular distributed grippers. Long and slim objects should select symmetric distributedgrippers.

2. Smaller objects should select tight grippers with short fingers. Bigger objects should select adjustable grippers with longer fingers.

3. Lighter objects can select small grippers with less fingers. Heavier objects can select big grippers with more fingers.

Wholesale high quality new stock pneumatic soft robot gripper



About us

Soft Robot Tech Co., Ltd. (SRT) is an innovative technology company based on software robotics technology. Its headquarters is located in Tianji Zhigu, Yizhuang Economic Development Zone, Beijing. Its R & D personnel are from Harvard University, Northeastern University of American, Beihang University and other well-known universities. SRT is committed to the promotion and application of soft robot technology in the field of industrial automation, providing customers with simple and reliable flexible grasping solutions for complex products, and continuously creating considerable value for users. It is a leading equipment manufacturer and service provider in China in terms of machine vision and industrial intelligence, it has several core technologies and independent intellectual property rights in the fields of visual positioning, visual measurement, visual inspection and visual recognition, and has been rated as a leading talent enterprise in Suzhou in 2020. It also focuses on the field of non-standard automation, and its main business is to provide intelligent manufacturing solutions for traditional manufacturing industry.



Headquarters: Beijing

4 Offices: Suzhou, Shenzhen, Zhangjiagang, Yongkang

16 Overseas agents: Japan, South Korea, Thailand, Malaysia, Singapore, France, Spain, Poland, Denmark, Netherlands, Belgium, Luxembourg, Colombia, Portugal, Canada,Bulgaria.

2 Subsidiaries in China
